NTT in Kyber (Round 3)

Basics

NTT & INTT

For a polynomial  the  'th root of unity  and the  'th root of unity

 with   with

The Cooley-Tukey (CT) butterfly

The CT algorithm splits the size-n input into one vector that contains the even-indexed values and another one that contains the odd-indexed values. After applying the NTT on both halves, denote by  the vector obtained from the even indexes and with  the vector obtained from the odd indexes. The full-size NTT vector  is obtained as follows: the first half of the resulting vector is computed as  and the second half as  with  from 0 to

The Gentleman-Sande (GS) butterfly

The GS algorithm splits the size-  input into one vector that contains the first  values and another one that contains the last  values. After applying the NTT on both halves, let us denote by  the vector obtained from the first  left indexes and with  the vector obtained from the last  right indexes. The final result  is obtained as follows: the even indexes of the resulting vector are updated as  and the second half as   with  from 0 to

NTT in Kyber

• CT NTT (Kyber round 3)

/*************************************************
* Name:        ntt
*
* Description: Inplace number-theoretic transform (NTT) in Rq
*              input is in standard order, output is in bitreversed order
*
* Arguments:   - int16_t r[256]: pointer to input/output vector of elements
*                                of Zq
**************************************************/
void ntt(int16_t r[256]) {
  unsigned int len, start, j, k;
  int16_t t, zeta;

  k = 1;
  for(len = 128; len >= 2; len >>= 1) {
    for(start = 0; start < 256; start = j + len) {
      zeta = zetas[k++];
      for(j = start; j < start + len; ++j) {
        t = fqmul(zeta, r[j + len]);
        r[j + len] = r[j] - t;
        r[j] = r[j] + t;
      }
    }
  }
}

• GS INTT (Kyber round 3)

/*************************************************
* Name:        invntt_tomont
*
* Description: Inplace inverse number-theoretic transform in Rq and
*              multiplication by Montgomery factor 2^16.
*              Input is in bitreversed order, output is in standard order
*
* Arguments:   - int16_t r[256]: pointer to input/output vector of elements
*                                of Zq
**************************************************/
void invntt(int16_t r[256]) {
  unsigned int start, len, j, k;
  int16_t t, zeta;

  k = 0;
  for(len = 2; len <= 128; len <<= 1) {
    for(start = 0; start < 256; start = j + len) {
      zeta = zetas_inv[k++];
      for(j = start; j < start + len; ++j) {
        t = r[j];
        r[j] = barrett_reduce(t + r[j + len]);
        r[j + len] = t - r[j + len];
        r[j + len] = fqmul(zeta, r[j + len]);
      }
    }
  }

  for(j = 0; j < 256; ++j)
    r[j] = fqmul(r[j], zetas_inv[127]);
}

Modular Reductions

Montgomery Reduction

/*************************************************
* Name:        montgomery_reduce
*
* Description: Montgomery reduction; given a 32-bit integer a, computes
*              16-bit integer congruent to a * R^-1 mod q,
*              where R=2^16
*
* Arguments:   - int32_t a: input integer to be reduced;
*                           has to be in {-q2^15,...,q2^15-1}
*
* Returns:     integer in {-q+1,...,q-1} congruent to a * R^-1 modulo q.
**************************************************/
int16_t montgomery_reduce(int32_t a)
{
  int32_t t;
  int16_t u;

  u = a*QINV;
  t = (int32_t)u*KYBER_Q;
  t = a - t;
  t >>= 16;
  return t;
}

Barrett Reduction

/*************************************************
* Name:        barrett_reduce
*
* Description: Barrett reduction; given a 16-bit integer a, computes
*              16-bit integer congruent to a mod q in {0,...,q}
*
* Arguments:   - int16_t a: input integer to be reduced
*
* Returns:     integer in {0,...,q} congruent to a modulo q.
**************************************************/
int16_t barrett_reduce(int16_t a) {
  int16_t t;
  const int16_t v = ((1U << 26) + KYBER_Q/2)/KYBER_Q;

  t  = (int32_t)v*a >> 26;
  t *= KYBER_Q;
  return a - t;
}
